- 98 mm
- 168 mm
- Status Light
- Gigabit Ethernet LAN Ports
- USB 2
- Gigabit Ethernet WAN Port
- Built-in Power Supply
- Dimensions: 98 mm (3.85 inches) by 98 mm (3.85 inches) by 168 mm (6.6 inches)
- Weight: 1.48 kg (3.26 pounds)1
|
2
|
2TB hard drive
3TB hard drive
|
|
- IEEE 802.11a/b/g/n/ac3
- Six-element beamforming antenna array
- Simultaneous dual-band 2.4GHz and 5GHz
- Radio output power: 32.5 dBm maximum (varies by country)
- Channels 1-11, 36-116, 132-140 and 149-165 approved for use in the United States and Canada
- Channels 1-13, 36-64, and 100-140 approved for use in Europe and Japan
- Channels 1-13, 36-64, and 149-165 approved for use in Australia, Hong Kong and New Zealand
|
|
- Interoperable with 802.11a, 802.11b, 802.11g, 802.11n, and 802.11ac-enabled Mac computers, iOS devices, Apple TV, Windows-based PCs, and other Wi-Fi devices
- NAT, DHCP, PPPoE, VPN Passthrough (IPSec, PPTP, and L2TP), DNS Proxy, IPv6 (6to4 and manual tunnels)
|
|
- Wi‑Fi Protected Access™ (WPA/WPA2)4
- WPA/WPA2 Enterprise4
- MAC address filtering
- NAT firewall
- 802.1X, PEAP, LEAP, TTLS, TLS, FAST
- Time-based access control
|
|
|
|
- Simultaneous dual-band 802.11ac wireless
- Gigabit Ethernet WAN port for connecting a DSL modem, cable modem, or Ethernet network
- USB 2 port for connecting a USB printer or hard drive5
- Three Gigabit Ethernet LAN ports for connecting a computer, Ethernet hub, or networked printer
- Built-in power supply
|
|
|
|
- 100–240V AC, 50–60Hz; input current: 1.5 amp
- Operating temperature: 0° to 35° C (32° to 95° F)
- Storage temperature: –25° to 60° C (–13° to 140° F)
- Relative humidity (operating): 20% to 80% noncondensing
- Operating altitude: tested up to 3000 m (10,000 feet)
- Maximum storage altitude: 4,500 metres (15,000 feet)
|
|
- FCC Part 15 Class B, Canada RSS-210, EN 300-328, EN 301-489, EN 301 893, ARIB STD-T66, RCR STD-T33, AS/NZS 4268: 2003, UL 60950, CSA-C22.2 No. 60950, GB 4943.1-2011
|
|
Setup and Administration
- iPhone, iPad, or iPod touch with iOS 6 or later and AirPort Utility 1.3
- Mac with OS X Lion v10.7.5 or later and AirPort Utility 6.3
Wireless Device Access
Any Wi‑Fi-enabled device that uses the 802.11a/b/g/n/ac specification
Shared Printing with a USB Printer
- USB printer
- Mac with OS X v10.2.7 or later
- PC with Windows XP (SP3), Windows Vista (SP2), Windows 7 (SP1), or Windows 8
Shared USB Hard Drive
- Mac with OS X v10.4.8 or later
- PC with Windows XP (SP3), Windows Vista (SP2), Windows 7 (SP1), or Windows 8
Backup using Time Machine
- Mac with OS X v10.5.7 or later
|
Apple takes a complete product life-cycle approach to determining our environmental impact. Learn more
AirPort Time Capsule is designed with the following features to reduce its environmental impact:
- Brominated flame retardant-free
- PVC-free6
- Meets ENERGY STAR 1.0 requirements for Small network equipment
Apple and the Environment
Learn more about Apple’s dedication to reducing the environmental impact of our products and process. The Apple Product Environmental Specification details the environmental attributes of our products.
Recycling
Apple takes a holistic view of materials management and waste minimisation. Learn more about how to recycle your Mac.
