Technical Specifications

Processor

Configure from an 8‑core to a 28‑core Intel Xeon W processor

8‑core

3.5GHz Intel Xeon W

8 cores, 16 threads

Turbo Boost up to 4.0GHz

24.5MB cache

Supports 2666MHz memory

12-core

3.3GHz Intel Xeon W

12 cores, 24 threads

Turbo Boost up to 4.4GHz

31.25MB cache

Supports 2933MHz memory

16-core

3.2GHz Intel Xeon W

16 cores, 32 threads

Turbo Boost up to 4.4GHz

38MB cache

Supports 2933MHz memory

24-core

2.7GHz Intel Xeon W

24 cores, 48 threads

Turbo Boost up to 4.4GHz

57MB cache

Supports 2933MHz memory

28-core

2.5GHz Intel Xeon W

28 cores, 56 threads

Turbo Boost up to 4.4GHz

66.5MB cache

Supports 2933MHz memory

Memory

Configure up to 1.5TB of DDR4 ECC memory in 12 user-accessible DIMM slots

32GB

Four 8GB DIMMs

48GB

Six 8GB DIMMs

96GB

Six 16GB DIMMs

192GB

Six 32GB DIMMs

384GB

Six 64GB DIMMs

768GB

Six 128GB DIMMs or 12 64GB DIMMs

1.5TB

12 128GB DIMMs

Requires 24-core or 28-core processor

8-core processor operates memory at 2666MHz

12-core to 28-core processors operate memory at 2933MHz

Graphics

Configure two MPX Modules with up to four GPUs

AMD Radeon Pro W5500X

24 compute units, 1536 stream processors

8GB of GDDR6 memory with 224GB/s memory bandwidth

Up to 5.6 teraflops single precision or 11.2 teraflops half precision

Two HDMI ports on card with support for 4K60

Two DisplayPort connections routed to the system to support internal Thunderbolt 3 ports

Support for up to four 4K displays, one 5K display or one Pro Display XDR

Half-height MPX Module fills an MPX bay and uses extra power and PCIe bandwidth

AMD Radeon Pro W6600X

32 compute units, 2048 stream processors

8GB of GDDR6 memory with 256GB/s memory bandwidth

Up to 9.8 teraflops single precision or 19.6 teraflops half precision

Two HDMI ports on card with support for 4K60

Up to four DisplayPort connections routed to system to support internal Thunderbolt 3 ports

Support for up to four 4K displays, two 5K displays or two Pro Display XDRs

Half-height MPX Module fills an MPX bay and uses extra power and PCIe bandwidth

AMD Radeon Pro W5700X

40 compute units, 2560 stream processors

16GB of GDDR6 memory with 448GB/s memory bandwidth

Up to 9.4 teraflops single precision or 18.9 teraflops half precision

Four Thunderbolt 3 ports and one HDMI port on card with support for 4K60

Two DisplayPort connections routed to the system to support internal Thunderbolt 3 ports

Support for Display Stream Compression (DSC)

Support for up to six 4K displays, three 5K displays or three Pro Display XDRs

Full-height MPX Module fills an MPX bay and uses extra power and PCIe bandwidth

AMD Radeon Pro W6800X

60 compute units, 3840 stream processors

32GB of GDDR6 memory with 512GB/s memory bandwidth

Up to 16.0 teraflops single precision or 32.0 teraflops half precision

Infinity Fabric Link connection enables two W6800X GPUs to connect at up to 84GB/s in each direction

Four Thunderbolt 3 ports and one HDMI port on card with support for 4K60

Two DisplayPort connections routed to the system to support internal Thunderbolt 3 ports

Support for up to six 4K displays, three 5K displays or three Pro Display XDRs

Full-height MPX Module fills an MPX bay and uses extra power and PCIe bandwidth

AMD Radeon Pro W6900X

80 compute units, 5120 stream processors

32GB of GDDR6 memory with 512GB/s memory bandwidth

Up to 22.2 teraflops single precision or 44.4 teraflops half precision

Infinity Fabric Link connection enables two W6900X GPUs to connect at up to 84GB/s in each direction

Four Thunderbolt 3 ports and one HDMI port on card with support for 4K60

Two DisplayPort connections routed to the system to support internal Thunderbolt 3 ports

Support for up to six 4K displays, three 5K displays or three Pro Display XDRs

Full-height MPX Module fills an MPX bay and uses extra power and PCIe bandwidth

AMD Radeon Pro W6800X Duo

Two W6800X GPUs, each with 60 compute units and 3840 stream processors

64GB of GDDR6 memory (32GB per GPU), each with 512GB/s memory bandwidth

Up to 30.2 teraflops single precision or 60.4 teraflops half precision

Onboard Infinity Fabric Link connection connects two W6800X GPUs at up to 84GB/s in each direction; external Infinity Fabric Link connection enables two W6800X Duo modules to connect four W6800X GPUs

Four Thunderbolt 3 ports and one HDMI port on card with support for 4K60

Four DisplayPort connections routed to the system to support internal Thunderbolt 3 ports

Support for up to eight 4K displays, four 5K displays or six Pro Display XDRs

Full-height MPX Module fills an MPX bay and uses extra power and PCIe bandwidth

Power Supply


1.4 kilowatts

Maximum continuous power:

1280W at 108–125V or 220–240V

1180W at 100–107V

Expansion Slots

Eight PCI Express expansion slots

Two MPX Modules or up to four PCI Express card slots

Each MPX bay provides:

x16 Gen 3 bandwidth for graphics

x8 Gen 3 bandwidth for Thunderbolt

DisplayPort video routing

Up to 500W of power for an MPX Module

Alternatively, each MPX bay can support:

One full-length, double-wide x16 Gen 3 slot and one full-length, double-wide x8 Gen 3 slot (MPX bay 1)

Or two full-length, double-wide x16 Gen 3 slots (MPX bay 2)

Up to 300W of auxiliary power via two eight-pin connectors

Three full-length PCI Express Gen 3 slots

One x16 slot; two x8 slots

75W of auxiliary power available

One half-length x4 PCI Express Gen 3 slot with Apple I/O card installed

Apple Afterburner

ProRes and ProRes RAW accelerator card

PCI Express x16 card

Accelerates ProRes and ProRes RAW codecs in Final Cut Pro, QuickTime Player X and supported third-party apps

Supports system playback of up to six streams of 8K ProRes RAW or up to 23 streams of 4K ProRes RAW1

Storage

Configure up to 8TB of SSD storage2

512GB SSD

One 512GB module

1TB SSD

Two 512GB modules

2TB SSD

Two 1TB modules

4TB SSD

Two 2TB modules

8TB SSD

Two 4TB modules

Up to 3.4GB/s sequential read and 3.4GB/s sequential write performance2

Storage encrypted by the Apple T2 Security Chip

Input/Output

I/O card installed in the half-length x4 PCI Express slot with:

Two USB 3 ports

Support for USB-A (up to 5 Gbps)

Two Thunderbolt 3 ports

Support for Thunderbolt 3 (up to 40 Gbps)

Support for USB-C (up to 10 Gbps)

Support for DisplayPort

Two 10Gb Ethernet ports:

Support for 10Gb Ethernet performance over copper cabling

Support for Nbase-T industry standard: 1Gb, 2.5Gb, 5Gb and 10Gb Ethernet link speeds using RJ-45 connectors




Additional Connections

Two Thunderbolt 3 ports on the top of the tower enclosure

Support for Thunderbolt 3 (up to 40 Gbps)

Support for USB-C (up to 10 Gbps)

Support for DisplayPort

Two Thunderbolt 3 ports on the front of the rack enclosure

Support for Thunderbolt 3 (up to 40 Gbps)

Support for USB-C (up to 10 Gbps)

Support for DisplayPort

Audio

Built-in speaker

3.5-mm headphone jack with headset support

Input Devices

Magic Keyboard with Numeric Keypad (silver and black)

Magic Mouse (silver and black)

Optional Magic Trackpad (silver and black)

Wireless

Wi-Fi

802.11ac Wi-Fi wireless networking

IEEE 802.11a/b/g/n compatible

Bluetooth®

Bluetooth 5.0 wireless technology

Enclosure

Tower

Mac Pro tower enclosure with feet; configurable to tower with wheels

Rack

Mac Pro rack enclosure with rack mounting rails

Dimensions

Tower

height: 52.9 cm
(20.8 inches)

width: 45.0 cm
(17.7 inches)

height: 52.9 cm
(20.8 inches)

depth: 21.8 cm
(8.58 inches)

Height with optional wheels:

55.7 cm (21.9 inches)

Rack

enclosure depth from handle: 53.95 cm
(21.24 inches)

handle depth: 4.60 cm
(1.81 inches)

enclosure depth from fascia: 49.35 cm
(19.43 inches)

height: 22.02 cm
(8.67 inches)
5U

Minimum rack depth:
60.96 cm
(24.0 inches)

Maximum rack depth:
106.68 cm
(42.0 inches)

height: 22.02 cm
(8.67 inches)
5U

depth: 48.2 cm
(18.98 inches)

Weight3

Tower

18.0 kg (39.7 pounds)

Rack

17.6 kg (38.8 pounds)

Electrical and Operating Requirements

Line voltage: 100–125V AC at 12A; 220–240V AC at 6A

Frequency: 50Hz to 60Hz, single phase

Operating temperature: 10° to 35° C (50° to 95° F)

Storage temperature: –40° to 47° C (–40° to 116° F)

Relative humidity: 5% to 95% noncondensing

Maximum altitude: Tested up to 5,000 metres (16,400 feet)

Limited Warranty and Service

Products that you purchase in New Zealand are covered by New Zealand consumer law. For more details, click here.

Your Mac Pro also comes with 90 days of complimentary technical support and a one-year limited warranty from Apple. To learn more about how Apple will service your Mac Pro, click here.

Purchase AppleCare+ for Mac to get up to three years of expert technical support and coverage for unlimited repairs for accidental damage from handling, each subject to a service fee of NZ$169 for external enclosure damage, or NZ$499 for other accidental damage. Coverage begins on your AppleCare+ purchase date. For more information, click here.

In the Box

Tower

Mac Pro

Magic Keyboard with Numeric Keypad

Magic Mouse

USB-C to Lightning Cable (1 m)

Power cord (2 m)

Rack

Mac Pro

Rack mounting rails (ship in a separate box)

Magic Keyboard with Numeric Keypad

Magic Mouse

USB-C to Lightning Cable (1 m)

Power cord (2 m)

Operating System

macOS

macOS is the most advanced desktop operating system in the world. macOS Ventura makes the things you do most on Mac even better, so you can work smarter, play harder and go further.

Learn moreabout macOS

Accessibility
Accessibility features help people with disabilities get the most out of their new Mac Pro. With built-in support for vision, hearing, mobility and learning, you can create and do amazing things.
Learn more about accessibility

Features include:

  • Voice Control
  • VoiceOver
  • Zoom
  • Increase Contrast
  • Reduce Motion
  • Siri and Dictation
  • Switch Control
  • Closed Captions
  • Text to Speech
Built-in Apps4
App Store
Books
Calendar
Contacts
FaceTime
Find My
GarageBand
Home
iMovie
Keynote
Mail
Maps
Messages
Music
Notes
Numbers
Pages
Photo Booth
Photos
Podcasts
Preview
QuickTime Player
Reminders
Safari
Shortcuts
Siri
Stocks
Time Machine
TV
Voice Memos
Kits and Accessories

Displays

  • Pro Display XDR
  • Studio Display

Graphics

  • Radeon Pro W5500X MPX Module Kit
  • Radeon Pro W6600X MPX Module Kit
  • Radeon Pro W5700X MPX Module Kit
  • Radeon Pro W6800X MPX Module Kit
  • Radeon Pro W6900X MPX Module Kit
  • Radeon Pro W6800X Duo MPX Module Kit
  • Apple Afterburner Kit

Memory

  • Apple 16GB DDR4 ECC Memory Kit
  • Apple 32GB DDR4 ECC Memory Kit
  • Apple 64GB DDR4 ECC Memory Kit
  • Apple 128GB DDR4 ECC Memory Kit
  • Apple 256GB DDR4 ECC Memory Kit

Storage

  • Apple 1TB SSD Kit
  • Apple 2TB SSD Kit
  • Apple 4TB SSD Kit
  • Apple 8TB SSD Kit
  • Promise Pegasus R4i 32TB RAID MPX Module Kit
  • Promise Pegasus J2i

Mac Software

Other Accessories

  • AppleCare+ for Mac
  • Feet Kit
  • Wheels Kit
  • Belkin Lock Adapter for Mac Pro
  • Belkin AUX Power Cable Kit for Mac Pro
  • Logitech Pro Magnetic Webcam

Mac Pro and the Environment

Apple takes a complete product life cycle approach to determining our environmental impact. Learn moreabout Mac Pro and environment

Mac Pro is designed with the following features to reduce its environmental impact:

  • Made with better materials
  • Enclosure made with low-carbon aluminium
  • Responsible packaging
  • Recyclable, majority-fibre packaging
  • 100 per cent of primary wood fibre comes from responsibly managed forests
  • Energy-efficient
  • Meets ENERGY STAR® requirements5
  • Smarter chemistry
  • BFR-, PVC- and beryllium-free

Recycling

Apple takes a holistic view of materials management and waste minimisation.

Learn more about how to recycle your Mac

Learn more

Read the Mac Pro Environmental Report for detailed information on its environmental performance.
