Mac mini Technical Specifications
Silver
Apple M4 chip
- 10-core CPU with 4 performance cores and 6 efficiency cores
- 10-core GPU
- Hardware-accelerated ray tracing
- 16-core Neural Engine
- 120GB/s memory bandwidth
Media Engine
- Hardware-accelerated H.264, HEVC, ProRes, and ProRes RAW
- Video decode engine
- Video encode engine
- ProRes encode and decode engine
- AV1 decode
Not configurable
Apple M4 chip
- 10-core CPU with 4 performance cores and 6 efficiency cores
- 10-core GPU
- Hardware-accelerated ray tracing
- 16-core Neural Engine
- 120GB/s memory bandwidth
Media Engine
- Hardware-accelerated H.264, HEVC, ProRes, and ProRes RAW
- Video decode engine
- Video encode engine
- ProRes encode and decode engine
- AV1 decode
Not configurable
Apple M4 chip
- 10-core CPU with 4 performance cores and 6 efficiency cores
- 10-core GPU
- Hardware-accelerated ray tracing
- 16-core Neural Engine
- 120GB/s memory bandwidth
Media Engine
- Hardware-accelerated H.264, HEVC, ProRes, and ProRes RAW
- Video decode engine
- Video encode engine
- ProRes encode and decode engine
- AV1 decode
Not configurable
Apple M4 Pro chip
- 12-core CPU with 8 performance cores and 4 efficiency cores
- 16-core GPU
- Hardware-accelerated ray tracing
- 16-core Neural Engine
- 273GB/s memory bandwidth
Media Engine
- Hardware-accelerated H.264, HEVC, ProRes, and ProRes RAW
- Video decode engine
- Video encode engine
- ProRes encode and decode engine
- AV1 decode
Configurable to:
- M4 Pro with 14‑core CPU and 20‑core GPU
Apple Intelligence is the personal intelligence system that helps you write, express yourself, and get things done effortlessly. With groundbreaking privacy protections, it gives you peace of mind that no one else can access your data — not even Apple.
16GB
- 16GB unified memory
Configurable to:
- 24GB or 32GB
16GB
- 16GB unified memory
Configurable to:
- 24GB or 32GB
24GB
- 24GB unified memory
Configurable to:
- 32GB
24GB
- 24GB unified memory
Configurable to:
- 48GB or 64GB
256GB
- 256GB SSD
Configurable to:
- 512GB, 1TB, or 2TB
512GB
- 512GB SSD
Configurable to:
- 1TB or 2TB
512GB
- 512GB SSD
Configurable to:
- 1TB or 2TB
512GB
- 512GB SSD
Configurable to:
- 1TB, 2TB, 4TB, or 8TB
M4
Simultaneously supports up to three displays:
- Up to three displays: Two displays with up to 6K resolution at 60Hz over Thunderbolt and one display with up to 5K resolution at 60Hz over Thunderbolt or 4K resolution at 60Hz over HDMI
- Up to two displays: One display with up to 5K resolution at 60Hz over Thunderbolt and one display with up to 8K resolution at 60Hz or 4K resolution at 240Hz over Thunderbolt or HDMI
Thunderbolt 4 digital video output
- Support for native DisplayPort 1.4 output over USB-C
M4 Pro
Simultaneously supports up to three displays:
- Up to three displays: Three displays with up to 6K resolution at 60Hz over Thunderbolt or HDMI
- Up to two displays: One display with up to 6K resolution at 60Hz over Thunderbolt and one display with up to 8K resolution at 60Hz or 4K resolution at 240Hz over Thunderbolt or HDMI
Thunderbolt 5 digital video output
- Support for native DisplayPort 2.1 output over USB‑C
HDMI display video output
- Support for one display with up to 8K resolution at 60Hz or 4K resolution at 240Hz (M4 and M4 Pro)
- Supported formats include HEVC, H.264, AV1, and ProRes
- HDR with Dolby Vision, HDR10+/HDR10, and HLG
- Supported formats include AAC, MP3, Apple Lossless, FLAC, Dolby Digital, Dolby Digital Plus, and Dolby Atmos
- Built-in speaker
- 3.5 mm headphone jack with advanced support for high-impedance headphones
- HDMI port supports multichannel audio output
On front:
- Two USB-C ports with support for USB 3 (up to 10Gb/s)
- 3.5 mm headphone jack
On back (M4):
- Gigabit Ethernet port (configurable to 10Gb Ethernet)
- HDMI port
Three Thunderbolt 4 (USB-C) ports with support for:
- Thunderbolt 4 (up to 40Gb/s)
- USB 4 (up to 40Gb/s)
- DisplayPort
On back (M4 Pro):
- Gigabit Ethernet port (configurable to 10Gb Ethernet)
- HDMI port
Three Thunderbolt 5 (USB-C) ports with support for:
- Thunderbolt 5 (up to 120Gb/s)
- USB 4 (up to 120Gb/s)
- DisplayPort
Wi-Fi
- Wi-Fi 6E (802.11ax)3
Bluetooth
- Bluetooth 5.3
Ethernet
- 10/100/1000BASE-T Gigabit Ethernet (RJ-45 connector)
- Configurable to 10Gb Ethernet (Nbase-T Ethernet with support for 1Gb, 2.5Gb, 5Gb, and 10Gb Ethernet using RJ-45 connector)
Line voltage: 100–240V AC
Frequency: 50Hz to 60Hz, single phase
Maximum continuous power: 155W
Operating temperature: 50° to 95° F (10° to 35° C)
Storage temperature: –40° to 116° F (–40° to 47° C)
Relative humidity: 5% to 90% noncondensing
Operating altitude: tested up to 16,400 feet (5000 meters)
Typical acoustical performance: Sound pressure level (operator position): 5 dBA at idle5
Your Mac mini comes with 90 days of complimentary technical support and a one‑year limited warranty. Purchase AppleCare+ for Mac to extend your coverage from your AppleCare+ purchase date and add unlimited repairs for accidental damage from handling, each subject to a service fee of $99 for screen damage or external enclosure damage, or $299 for other accidental damage, plus applicable tax.
- Mac mini
- Power cord (1.8 m)
macOS
macOS is the most advanced desktop operating system in the world. macOS Sequoia helps you be productive and creative in new ways — with Apple Intelligence,1 iPhone Mirroring, window tiling, major updates to Safari, and more.
Accessibility features help people with disabilities get the most out of their new Mac mini. With built-in support for vision, hearing, mobility, and learning, you can create and do amazing things.
Features include:
- Voice Control
- VoiceOver
- Zoom
- Increase Contrast
- Reduce Motion
- Siri and Dictation
- Switch Control
- Closed Captions
- Text to Speech
Configure your Mac mini with these options at apple.com:
Model 1
- Not configurable
- 24GB or 32GB unified memory
- 512GB, 1TB, or 2TB SSD
- 10Gb Ethernet
Model 2
- Not configurable
- 24GB or 32GB unified memory
- 1TB or 2TB SSD
- 10Gb Ethernet
Model 3
- Not configurable
- 32GB unified memory
- 1TB or 2TB SSD
- 10Gb Ethernet
Model 4
- M4 Pro with 14‑core CPU, 20‑core GPU, and 16‑core Neural Engine
- 48GB or 64GB unified memory
- 1TB, 2TB, 4TB, or 8TB SSD
- 10Gb Ethernet
